Still RX 20 1.4 – 2.0 Tonne

The Still RX 20 electric forklift range is available with various lifting capacities from 1.4t to 2.0t, various mast options with heights up to nearly 8m and a powerful 48v battery. The German logistics magazine Logistikwelt, recently awarded the RX20 the best in class award, when compared to its competitors, scoring particularly well in driving characteristics and Handling which is perhaps why these forklifts are very popular with companies such as DHL, Frankfurt Airport and BMW.

Highlights:

  • Simple side battery change large field of modular concept
  • Three-phase drive is optimised for maximum energy and minimum noise
  • Powerful 48v battery

A WORLD FIRST: THE SIDE BATTERY CHANGE.

Safe Use

In addition to its fantastic driving characteristics, the RX20 has a variable speed control facility, for applications where on site speed limits are important. The RX 20 range also comes with a clear view mast which allows the driver far better view of their load and what is in front of them. There is a choice of rear wheel options on the RX 20 2 tonne model:

  1. Close coupled rear wheels which provide significant turning circle advantages, for applications where space is at a premium.
  2. The standard 4 wheel model (RX 20: 2.0p) with regular corner mounted wheels, which doesn’t have quite the same narrow turning circle, but does offer some stability advantages where work areas are not so smooth.

DRIVE

The three-phase drive of the RX 20 forklift is optimised for maximum energy and minimum noise. Operating on the front wheels, it provides a consistent, high power output. Its newly-developed control system provides superb driving dynamics – even when operating on uneven floors or gradients.
In addition, thanks to the electrical regenerative braking, the motors feed back up to 15% of the energy into the battery, depending on the application, thus extending the useful life of a battery charge by up to 1.5 hours. This often makes top-up charges, or a battery change unnecessary during a shift.

SERVICE

Maintenance intervals for the RX 20 range is 1000 hours or 12 months. The robust controller is of modular construction. The counterweight was designed using heat simulation calculations to allow heat generated by the efficiency-optimised power components to be dissipated without the use of fans or air filters. All electrical components are individually monitored diagnostically to allow the fastest possible fault-finding and thereby reduced repair time and cost. The oil immersed multi-disc brakes are also maintenance-free.

THE CONSTRUCTION KIT PRINCIPLE

Due to the unique construction kit concept, the RX20 electric forklift truck can be built to match the application precisely. This makes many variations possible. According to the demands of the operation in respect of loads, aisle widths, battery capacity and headroom (a variety of masts is available), a virtually bespoke forklift truck can be supplied, providing you with the most efficient handling solution.

Please Contact us for prices and financing options.

For Forklift sales, we are the Still main distributor. We cover the entire region, including Cardiff, Bristol, Swansea Newport and Hereford. Please contact us.
